THE CULMINATION OF SONIC OBSESSION.

SVS Ultra Evolution Bookshelf speaker represents the culmination of SVS breakthroughs in driver design, component materials, and cabinet architecture, married with a relentless passion for audio excellence. The science of sonic perfection in harmony with a love of convincing and immersive sound.

With a big, expansive sound that’s revealing and detailed, Ultra Evolution Bookshelf gives the impression of a much larger speaker without sacrificing refinement or accuracy.

Never has this fusion of design elements existed in a single speaker. Time aligned cabinet geometry, diamond coated aluminium dome tweeters, organic cellular lattice diffuser, and other advancements embody an uncompromising approach to speaker design. These innovations are brought to life with painstaking anechoic and real-world measurement and voicing. This final bit of artistry places Ultra Evolution Bookshelf among the highest fidelity speakers ever created.

SVS’s mission has always been to ignite a passion for transcendent music and home theatre experiences by rendering the truest sonic playback.

The joy of pristine clarity, absolute transparency, stunning dynamics, and effortless bass for more people than ever. SVS Ultra Evolution Bookshelf deeply connects you to the emotion of sound.

INSPIRED DESIGN, REFERENCE PERFORMANCE.

Acoustically Centred Time Alignment Cabinet Architecture

• Curved front baffle aligns the sonic emanation point of all drivers on a vertical plane ensuring sound from each driver reaches your ears at the exact same instant.
• Maximises phase coherence for more convincing and immersive soundstage with pinpoint accuracy and imaging.
• Midrange drivers and woofers positioned above and below the tweeter allow for seamless crossover blending to create an idealised “point-source” where sound flows from single point in front of the speaker to optimise dispersion characteristics.

Diamond Coated Aluminum Dome Tweeter

• Through a process called Vapor Deposition, a layer of diamond carbon is applied to the aluminium dome tweeters to vastly improve rigidity and acoustic properties.
• This breakthrough in material science raises the frequency response well beyond the limits of human hearing resulting in effortless, airy, and unveiled highs with no measurable distortion.
• The diamond coating also pushes low frequency extension of the tweeter deeper for more seamless blending with the midrange.
• Organic cell lattice tweeter diffuser protects the dome and employs semi-random pattern derived from organic cell structures to improve off-axis response and maximise the listening “sweet spot.”

Quad 8” Glass Fibre Woofers in Force Balanced Array

• Dual opposing active woofers on the top and bottom of the cabinet render effortless low frequency response while addressing room modes. Deep, authoritative bass is evenly spread throughout the listening area.
• Mechanical energy from each front-firing woofer is equaled inside the cabinet by the rear-firing woofer eliminating mechanical coloration for pure, accurate low frequencies at any playback level.

5.25" Glass Fibre Composite Midrange Drivers

• Superb stiffness to mass ratio on dual driver array conveys stunning dynamics with flawless tonal accuracy.

Unrelenting Attention to Detail

• Acoustically tuned enclosure optimises low frequency tuning and eliminates any potential for cabinet resonances, resulting in pristine sound across the frequency spectrum.
• Uncompromising 2-Way crossover with premium components seamlessly blends driver output. Subtle musical details are rendered with breathtaking clarity, while massive dynamics radiate with weight and control from the highest to lowest octaves.
• Precision-cast aluminium-alloy baskets ensure precise alignment of critical components and maximise thermal dissipation.
• Chamfered front baffle minimises edge diffraction for optimal off-axis frequency response.
• Neodymium magnetic grilles
• Stunning Piano Gloss Black, Piano Gloss White, and Black Oak Veneer Finish

Specifications:

Frequency Response / Acoustic Data

• Frequency Response: 24Hz to 40kHz (+/-3 dB)
• Nominal Impedance: 6 ohms
• Sensitivity: 88dB (2.83V @ 1 meter full-space, 300Hz – 3kHz)
• Recommended amplifier power: 20 – 300 watts

Speaker Specs

• Floor-standing Tower Loudspeaker
• Piano gloss black, piano gloss white, real black oak veneer finish options
• Dual gold-plated 5-way binding posts
• Dual 3” wide-flared rear-firing ports 
• Cloth grille with magnetic retention system
• Elastomer screw-in feet – adjustable for level
• Spiked metal screw-in feet included – adjustable for level
• Cabinet Dimensions: 49.61” (H) x 11.81” (W) x 18.14” (D) / 1260mm (H) x 300mm (W) x 460.7mm (D)
• Overall Dimensions: 50.2” (H) x 11.81” (W) x 18.14” (D) / 1275mm (H) x 300mm (W) x 460.7mm (D) (includes grille, feet, and binding posts)
• Weight Unboxed: 96.7 pounds / 43.9 kgs

Driver Specs - 1” Diamond Coated Tweeter

• FEA-optimised Organic Cell Lattice Diffuser for airy, unveiled highs and pristine clarity.
• Cutting-edge vapor-deposition grows a hyper-rigid diamond-like coating on an aircraft-grade aluminium dome, pushing high-frequency extension further beyond human hearing, and delivering best-in-class fidelity, linearity, and transient response.
• Silver tinsel leads for optimal signal transfer and power handling.

Driver Specs - 5.25” Midrange Drivers

• Composite glass-fibre cone with excellent stiffness/mass ratio for high sensitivity and pistonic behaviour beyond passband.
• Precision-cast aluminium-alloy baskets ensure precise alignment of critical components and maximise thermal dissipation.
• Vented Kapton voice coil former is exceptionally lightweight for excellent dynamics and transient response.

Driver Specs - 8” Woofers

• Long stroke motor and suspension for high output.
• Composite glass-fibre cone with excellent stiffness/mass ratio for high sensitivity and pistonic behaviour beyond passband.
• Precision-cast aluminium alloy baskets ensure precise alignment of critical components and maximise thermal dissipation.
• Vented aluminium voice coil former to maximise thermal control while minimising air compression artefacts at high drive levels.

Crossover

• 3-way crossover with premium-grade capacitors, inductors, resistors and heavy-trace printed circuit board
• Tweeter-to-Midrange crossover: 1.8 kHz
• Midrange-to-woofer crossover: 140 Hz

Cabinet
