Overview

AT-OC9XEN

Category
Turntable Cartridges
SKU
OC9XEN

Not sure it's the right fit for your room or system? Our team can talk you through it.

Call 1300 308 711
Our thoughts

Discover the enigmatic audio reproduction of the Audio Technica AT-OC9XEN Dual Moving Coil Cartridge. Meticulously engineered with the Nude Elliptical stylus and Pure Copper by Ohno Continuous Casting coils, this cartridge is meant to heighten your audio experience by ensuring pure audio transmission with mesmerising channel separation. Its unique reverse V-shaped coil alignment minimises distortion and maximises record groove tracking. The durable aluminum body suppresses resonance, while the potent blend of a neodymium magnet and pure iron yoke escalates the magnetic energy to new heights. The cartridge's pre-threaded body ensures a simple mounting procedure, making it the perfect addition to your hi-fi sound system. Experience authentic, undisturbed and superior sound with the AT-OC9XEN, the epitome of Audio Technica's high-quality audio innovation.

The Audio Tailor team, Murarrie showroom

Introducing the Audio Technica AT-OC9XEN Dual Moving Coil Cartridge

The Audio Technica AT-OC9XEN Dual Moving Coil Cartridge is the perfect blend of musical purity and technological innovation. Elevate your listening experience with its exceptional channel separation and independent Dual Moving Coil design. The cartridge's Pure Copper by Ohno Continuous Casting (PCOCC) coils ensure vibrant, distortion-free tones that are transmitted purely. The coils are structured in a reverse V-formation, allowing minimal pressure on the stylus and minimizing distortions for the most authentic audio reproduction.

But that's not all. The AT-OC9XEN features a robust aluminum body that dissipates resonance, combined with a powerful neodymium magnet and an iron yoke for heightened magnetic energy. The cartridge's fragile, low-mass nude elliptical stylus, paired with an aluminum cantilever, extracts even the tiniest musical nuances from your records with unmatched precision.

What sets the AT-OC9XEN apart is its dexterously pre-threaded cartridge body, which ensures hassle-free mounting with just two screws, no nuts required. This sublime piece of audio equipment offers audiophile-grade sound engineered for discerning ears.

Features:

  1. Premium Dual Moving Coil Design: The AT-OC9XEN is expertly designed with two independent coils for exceptional channel separation and euphonic stereo imaging.

  2. Reverse V-Shaped Coil Formation: The unique reverse V-formation of the PCOCC coils minimizes pressure on the stylus, reducing audio distortion.

  3. Pre-threaded Cartridge Body: The cartridge body is pre-threaded for easy mounting, eliminating the need for additional nuts.

  4. Low Mass Nude Elliptical Stylus and Aluminum Cantilever: The cartridge features a speciously designed, low-mass nude elliptical stylus and lightweight aluminum cantilever for precision tracking and outstanding sound reproduction.

  5. Augmented Magnetic Energy: The cartridge's high-performance neodymium magnet and pure iron yoke enhance its magnetic energy for superior audio deliverance.

  6. Durable Aluminum Body: The AT-OC9XEN has a robust aluminum shell that reduces vibrations, resonance, and enhances audio playback.

  7. Top-grade PCOCC Coils: The coils, made from pure copper by Ohno Continuous Casting, ensure superlative signal transfer for a high fidelity audio experience.

Benefits:

  1. Stellar Sound Reproduction: The dual moving coil design and low pressure exerted on the stylus guarantee an audiophile-approved, distortion-less audio playback.

  2. Easy Installation: The pre-threaded cartridge body makes installation quick and comfortable, without the need for additional fastenings.

  3. Optimal Tracking: The lightweight nude elliptical stylus and aluminum cantilever ensure accurate tracking for authentic and nuanced audio playback.

  4. Enhanced Audio Output: The cartridge's high magnetic energy contributes to robust and richer audio output.

  5. Reduced Resonance: The sturdy aluminum body efficiently absorbs vibrations, reducing resonance for an elevated listening experience.

  6. Pure Signal Transmission: The top-grade PCOCC coils ensure undiluted signal transmission, bringing the listener closer to the original recording.

Specifications:

Specification Detail
Product AT-OC9XEN Dual Moving Coil Cartridge
Stylus Design Nude Elliptical
Stylus Material Nude square shank
Coil Design Dual Moving Coil
Coil Material Pure Copper by Ohno Continuous Casting (PCOCC)
Coil Alignment Reverse V-shaped formation
Magnet Type Neodymium magnet
Yoke Material Pure iron
Cantilever Material Aluminum
Cartridge Body Material Aluminum
Cartridge Body Feature Pre-threaded
Cartridge Mounting Two screws – no nuts required
Frequency Response 20-30,000 Hz
Channel Separation 25 dB (1 kHz)
Vertical Tracking Angle 20°
Vertical Tracking Force 1.8-2.2 g (2.0 g standard)
Distortion Reduction Reduced pressure on stylus thanks to coil alignment
Vibration Reduction Rigid aluminum body
Enhanced Audio Quality Reduction in resonance and increased magnetic energy
Pure Signal Transfer PCOCC coils for pure and untarnished audio experience

Experiencing the Audio Technica AT-OC9XEN Dual Moving Coil Cartridge is embarking on an auditory expedition where perfection is the destination. Its transformational technology guides you through intricate melodies and delicate details, resonating with unrivaled clarity. It's not just a product; it's a journey into the realm of high-fidelity audio, erasing the line between the artist and the audience. Choose the Audio Technica AT-OC9XEN and welcome to your new audio experience.

Specifications

Technical details

Manufacturer specifications. Want to know how it compares with something else? Ask our team.

| Specification | Detail | | - | - | | Product | AT-OC9XEN Dual Moving Coil Cartridge | | Stylus Design | Nude Elliptical | | Stylus Material | Nude square shank | |Coil Design | Dual Moving Coil | | Coil Material | Pure Copper by Ohno Continuous Casting (PCOCC) | | Coil Alignment | Reverse V-shaped formation | | Magnet Type | Neodymium magnet | | Yoke Material | Pure iron | | Cantilever Material | Aluminum | | Cartridge Body Material | Aluminum | | Cartridge Body Feature | Pre-threaded | | Cartridge Mounting | Two screws – no nuts required | | Frequency Response | 20-30,000 Hz | | Channel Separation | 25 dB (1 kHz) | | Vertical Tracking Angle | 20° | | Vertical Tracking Force | 1.8-2.2 g (2.0 g standard) | | Distortion Reduction | Reduced pressure on stylus thanks to coil alignment | | Vibration Reduction | Rigid aluminum body | | Enhanced Audio Quality | Due to reduction in resonance and increased magnetic energy | | Pure Signal Transfer | Owing to the use of PCOCC for the coils |
