IsoTek - EVO3 Ascension - Power Cable
EVO3 Ascension takes IsoTek’s power cable designs and technical innovations to a new level.
This unique design consists of deep cryogenically treated silver plated Ohno continuous cast copper conductors, wrapped in a dielectric of air, with partial FEP contact, before a further extruded FEP sleeve seals the construction. Each of these individual conductor assemblies are wrapped in Mylar with a further OFC shield before being given a slight rotational twist with FEP tubes of air.
Ascension drops the noise floor to an inky black level, opens the soundstage with holographic images, air and space and unparalleled micro dynamics. Astonishing.
CONSTRUCTION: The conductors are in a parallel configuration with a slight rotational twist. This established technique remains the first line of defence against RFI and EMI rejection.
A) Conductors: 4.0sqmm silver-plated Ohno Continuous Cast copper conductors offer a vastly superior level of purity compared with traditional OFC. Each conductor is deep cryogenically treated down to -196° C. The geometry and metallurgy used in this cable offer superb performance with extremely impressive electrical conductivity.
B) Dielectric: To obtain a dielectric constance close to a vacuum, IsoTek has created a Virtual Air Dielectric offering just 1.0548 dielectric constance. This air barrier is achieved by minimal conductor contact and the use of an FEP (Teflon) bridge. FEP is an excellent dielectric in its own right, with low coefficient, and the first choice for safety in both temperature and electrical insulation.
C) Filler: Clear FEP (Teflon) air tubes surround each conductor maintaining low dielectric constance and cable construction stability.
D) Wrap: Each conductor assembly is wrapped in Mylar to offer individual conductor shielding as well as a further barrier against RFI.
E) Jacket: PVC is used as the outer jacket to give a high degree of flexibility and mechanical damping and strength.
The Ascension cable is terminated using IsoTek’s bespoke ultra high grade audiophile connectors of solid OFC with pure silver-plated conductors. These offer the highest level of conductivity and quality performance.
IsoTek Ascension's complex construction delivers extended openness, a sound with more perceived micro dynamic detail, and inner space and air between instruments within the soundstage.
- Conductor Size - 3 x 4.0sqmm
- Conductor Material - Silver plated Ohno continuous cast copper (OCC)
- Conductor Treatment - Deep Cryogenic - 196°C
- Dielectric - Air with partial Fluorinated Ethylene Propylene (FEP) contact
- Filler - Fluorinated Ethylene Propylene (FEP) tubes of air
- PVC Barrier - Mylar/OFC braid
- Outer Jacket - High flexibility PVC
- Power Rating - 16 Amp
- Cable Length - 2.0m standard (custom lengths available)
- Outer Diameter - 17.5mm
- Termination - Silver-plated OFC audiophile-grade connectors
- Suitability - Suitable for CD players, preamps, tuners, power amps, Blu-ray players, music servers, TVs, soundbars and more!
